Introducing the PDI 500,
The first passive direct box module for your 500 series rack.
Features
~ API form factor, fits in your API 500 series compatible rack
~ VPR Alliance approved
~ 1/4" gold plated input and thru jacks
~ Thru jack can be selected as a summed input
~ Pad button attenuates hot input signals 10dB
~ -20 button adds an extra 10dB's of attenuation
~ Polarity/∅ reverses output signal
~ G-Lift removes the ground circuit, eliminating hum and buzz
~ Available with Jensen or Cinemag transformer
~ Logic controled relays for optimized signal path
~ Hand assembled in Hollywood, CA
~ Metalwork made in our own CNC equipped machine shop
~ Affordable price won't ruin your weekend plans
-=Click here to read the review in Tape Op Magazine=-
-=Click here to download manual=-
--------------------------------------------------------------------->
*Technical stuff for Jensen unit
Impedance Ratio: 200K:1.5K
Turns Ratio: 12:1
Linearity 20hz to 50Khz: +/- 0.05dB
Frequency Response plot 20Hz to 200KhzJensen transformer Frequency Response plot 20Hz to 200Khz
THD@100Hz: 0.0150
THD@1Khz: 0.0125
THD@15Khz: 0.011
THD vs. Frequency plot 20Hz to 200KhzJensen transformer THD vs. Frequency plot 20Hz to 200Khz
Phase shift@ 20Hz: -0.05
Phase shift@ 1Khz: +0.06
Phase shift@ 20Khz: +0.08
Phase vs. Frequency plot 20Hz to 50KhzJensen transformer Phase vs. Frequency plot 20Hz to 50Khz
------------------------------------------------------------------------------------------->
*Technical stuff for Cinemag unit
Impedance Ratio: 20K:150
Turns Ratio: 12:1
Linearity 20hz to 50Khz: +/- 0.05dB
Frequency Response plot 20Hz to 200KhzJensen transformer Frequency Response plot 20Hz to 200Khz
THD+N%@100Hz: 0.0150
THD+N%@1Khz: 0.0120
THD+N%@20Khz: 0.100
THD vs. Frequency plot 20Hz to 200KhzJensen transformer THD vs. Frequency plot 20Hz to 200Khz
Phase shift@ 20Hz: -0.10 deg
Phase shift@ 1Khz: +0.14 deg
Phase shift@ 20Khz: +0.01 deg
Phase vs. Frequency plot 20Hz to 50KhzJensen transformer Phase vs. Frequency plot 20Hz to 50Khz
*All Tests were performed on an Audio Precision System One. All graphs and data
generated from one randomly chosen PDI-500. No statistical averaging or weighting.
Phase shift referenced to source generator. 1K load on analyzer input.
-------------------------------------------------------------------------------------------------------->
